RADAN Radimport

Radimport at a glance

Automated Importing: Radimport processes DXF and CSV files in batches, eliminating manual tasks and saving time.

Geometry Healing: Automatically detects and fixes errors in imported files, ensuring clean and usable data for production.

Seamless Integration: Works effortlessly with RADAN’s Nesting software, enabling efficient workflow and project setup.

Customisable Solutions: Adapts to unique business needs with flexible input options and detailed CSV logging for better management.

RADAN Radimport

Automated Import and Processing of Geometry Data and Requirement Data

For most sheet working companies, the work preparation of parts for nesting is very time-consuming. With Radimport, geometry files are automatically converted to tooled RADAN parts. With the same mouse click, your selection of geometry files can be converted to a nest project.

Features at a glance:

  • Batch import DXF files
  • CSV lists from MRP
  • Geometry healing
  • Properties from DXF or CSV
  • Split multiple parts in same drawing
  • Creates RADAN Parts
  • Creates clean geometry DXFs
  • Send parts to RADAN Nester
  • CSV log file for MRP feedback
  • Automatic processing of watched directory
  • Manual overrides

Flexible input

With Radimport you can select multiple DXF or DWG files and add or edit the additional information. Importing files can also be done with a configurable parts list in a CSV format as you might get from an MRP system.

With Radimport you can select multiple DXF or DWG files and add or edit the additional information. Importing files can also be done with a configurable parts list in a CSV format as you might get from an MRP system.

Just what is needed

Based on the feature type, layer, line type or color, features can be changed or deleted. You just keep the information that is needed for cutting. At the same time, geometry errors can be fixed – like closing profile gaps and removing double lines and arcs. Text information can be transferred to attribute values: for example, material, sheet thickness and customer name.

Production information

Extra information can be added automatically to the part attributes. You can also engrave the article number, order number or bend line on a laser.

Optimum output

After the geometry conversion, the parts can be saved as RADAN parts or as an optimized clean DXF file. All the information like run time, weight and surface area can be saved as attributes in the part.

Nesting

Radimport can create a RADAN Nest Project from the parts you have imported. You have the option to edit the quantities and other properties of the parts before creating the Nest Project. Radimport can automatically launch the RADAN Nester for you to start nesting straight away.

Why Radimport?

Radimport eliminates time-consuming tasks and manual interventions in the sheet metal process, allowing teams to focus on higher-value work. The ability to batch import files, automatically resolve geometry errors, and transfer data to RADAN parts ensures that your project setup is faster and more accurate. With Radimport, you can speed up your workflow and reduce costly mistakes, resulting in improved productivity and better business outcomes.

Seamless Integration with RADAN As part of the RADAN suite of tools, Radimport works directly with RADAN’s Nesting software. Once your data is imported and processed, you can immediately begin nesting your parts, saving valuable time in the production cycle.

Who Can Benefit from Radimport? Radimport is ideal for sheet metal companies, fabricators, and manufacturers looking to streamline their operations, reduce errors, and improve efficiency. Whether you’re a small operation or a larger enterprise, Radimport helps you stay competitive by simplifying the workflow.

Get Started Today

Are you ready to optimize your sheet metal operations? Discover how Radimport can make a difference.

Click here

Some FAQ’s

1. What file types does Radimport support?

Radimport handles DXF files and CSV data, making it easy to integrate with your existing systems.

2. Does Radimport fix geometry errors automatically?

Yes, Radimport automatically identifies and resolves geometry errors during the import process, ensuring files are ready for nesting.

3. Can Radimport integrate with other software?

Radimport is designed to integrate seamlessly with RADAN’s Nesting software, streamlining your workflow from import to production.
